C2X booster

Manufacturer MPS Technology

This model is recommended for technical divers , CCR divers and boats. The two-stage booster with its lower driving air consumption is particularly suited for professional use and for diving centers.

CONSTRUCTION MATERIALS

Body: ergal, stainless steel 316, brass ot 58

Seals: fkm, ecopur, teflon, composit

Overcooled head and cylinder

TECHNICAL DATA

Pressure ratio: 25/1

Drive air: 9-10    bar

Piston stroke: 2 x 60 mm

Displacement: 2 x 20 cc

Max boost pressure: 340 bar

Min suction pressure: 5 bar

Min pumping speed: 15 cycles/minute

Max pumping speed: 140 cycles/minute

Weight: 14 kg

Dimensions: 46 x 12 x 18 cm

 For price and availability email info@tecdivegear.com.au or phone us on 0414926374
